MIL-DTL-62034G(AT)
TABLE II. Service products.
Ambient air temperature
-65 °F to 0 °F
-10 °F to 115 °F
Product use
(-54 °C to -18 °C)
(-23 °C to +46 °C)
Oil:
For hydraulic brakes
MIL-PRF-46176
MIL-PRF-46176
For general purpose
Commercial (water dispensing,
MIL-PRF-3150
lubrication
low temperature)
Grease:
For bearings
MIL-PRF-23827
MIL-PRF-23827
For general chassis
MIL-PRF-10924
MIL-PRF-10924
lubrication, including
wheel bearings
3.4.2 Payloads and speeds.
3.4.2.1 Highway operation. The semitrailer shall provide satisfactory operation over
smooth, hard-surfaced roads, when loaded with rated payload, as specified in table III, and at a
sustained speed of 50 miles per hour (mph) [80 kilometers per hour (km/h)] (see 4.5.4).
3.4.2.2 Cross-country operation. The semitrailer shall provide satisfactory operation
over unimproved roads, open, rolling or hilly terrain, when fully loaded with the rated payload,
as specified in table III and at a sustained speed of 20 mph (32 km/h) (see 4.5.4).
TABLE III. Weights and payloads.
Curb weight
Payload allowance minimum
Model
(pounds)
(pounds)
M118A1
8060 (3656 kg*)
12 000 (5443 kg)
M119A1
7160 (3248 kg)
12 000 (5443 kg)
M127A2C
13 000 (5902 kg)
24 000 (10 886 kg)
M128A2C
15 220 (6904 kg)
24 000 (10 886 kg)
M129A2C
15 400 (6985 kg)
24 000 (10 886 kg)
M349A3
8600 (3901 kg)
15 000 (6804 kg)
M349A4
8600 (3901 kg)
15 000 (6804 kg)
*kg = kilogram
3.4.3 Brake system.
6
