MIL-DTL-62034G(AT)
TABLE I. Drawing, model, and system voltage.
Drawing
Description
System voltage
8736092
Semitrailer, Stake, 6 Ton, 2-Wheel, M118A1.
24 volts
8736684
Semitrailer, Stake, 12 Ton, 4-Wheel, M127A2C.
12 & 24 volts
8736685
Semitrailer, Van, Cargo, 12 Ton, 4-Wheel, M128A2C.
12 & 24 volts
8736686
Semitrailer, Van, Supply, 12 Ton, 4-Wheel, M129A2C.
12 & 24 volts
8736687
Semitrailer, Refrigerator, 7 1/2 Ton, 2-Wheel, M349A3.
12 & 24 volts
8736746
Semitrailer, Refrigerator, 7 1/2 Ton, 2-Wheel, M349A4.
24 volts
8750501
Semitrailer, Van, Cargo, 6 Ton, 2-Wheel, M119A1.
24 volts
3.3.2 Lighting system. The internal and external lighting system, as specified on
applicable drawings, shall operate at the voltage listed in table I under all semitrailer operating
conditions. All electrical contacts and connections shall maintain positive contact under all
semitrailer operating conditions and have continuity from end to end of each circuit. The
external lighting system shall meet the applicable requirements of MIL-STD-1179 (see 4.5.2).
3.3.3 Tires and tubes.
3.3.3.1 Tires. Unless otherwise specified (see 6.2), tires shall be in accordance with
SAE J2014 (see 4.5.2).
3.3.4 Adjustment mechanisms. All adjustment mechanisms shall function properly and
maintain adjustment settings during all vehicle operating conditions (see 4.5.2).
3.4 Performance. Semitrailer shall meet performance requirements of this specification
when fully equipped, loaded with applicable payload and serviced with products specified in
table II, and coupled with an applicable prime mover. Semitrailer serviced and equipped for
existing climatic conditions shall operate as specified without special equipment.
3.4.1 Environmental conditions. The semitrailer shall operate under extreme conditions
in ambient air temperatures ranging from minus (-) 50 degrees Fahrenheit (°F)
[-46 degrees Celsius (°C)] to plus (+) 125 °F (52 °C). The complete semitrailer when in storage
shall withstand -80 °F (-62 °C) without deterioration that may cause failure of any component of
the semitrailer (see 4.5.3).
5
