MIL-DTL-62073H(AT)
TABLE I. 24V connector pin assignments.
Pin
Use
A
24V left blackout tail
B
Circuit 3 (8V-30V)
C
24V right blackout tail
D
Circuit 1 ground
E
Circuits 2 and 6 (8V-30V service)
F
24V blackout stop
H
Not used
J
Circuit 5 (8V-30V right turn)
K
Not used
L
Circuit 1 ground
M
Not used
N
Not used
3.5.4 Adjustment mechanisms. Adjustment mechanisms shall function properly and
maintain adjustment settings during all trailer operating conditions (see 4.6.3.i).
3.5.5 Safety chains. The trailer shall have safety chains attached to be used when the
trailer is connected to the prime mover (see 4.6.3.j). The safety chain assembly shall conform
to drawing 12441163.
3.5.6 Transportability. The transportability performance requirements for the trailer,
shall be in accordance with MIL-STD-1366 and MIL-STD-209 (see 4.6.3.k).
3.5.6.1 Lifting/tiedown provisions. The trailer shall be equipped with lifting/tiedown
provisions to secure the trailer and cargo during transport and to lift the vehicle. The provisions
shall be in accordance with MIL-STD-209 and MIL-STD-810 (see 3.6, 4.6.3.l).
3.5.6.2 Marine Transport. The trailer shall be marine transportable when coupled to
the prime mover and with a payload equivalent to an empty M1061A1 trailer. The trailer shall
be in accordance with Roll On/Roll Off (RO/RO) marine transportability requirements of
MIL-STD-1366. The trailer shall be capable of entering, cresting and leaving a 15 degree
ramp.
3.5.6.3 Lifting Provisions. The trailer, with rated payload, shall be equipped with
lifting provisions that meet the design requirements of type I of the latest version of
MIL-STD-209, and be able to lift the trailer with full payload. Non-welded parts of the lifting
provisions shall be hot dip galvanized. Lifting provisions shall have chamfered edges. Lifting
provisions shall be recessed below the level of the deck. Each of the trailer lifting eye recessed
pockets shall have a drain hole.
8
