MIL-C-52437/6
TABLE I. Military design size 9 chassis. (Cont'd)
Load range
Tire inf. press.
Option B:
No. of axles
- GAWR, ea. axle at hubs
- No, trailer tires
No. spare tires
Tire size
Load range
Tire inf. press.
Bed length, A
117 in.
Bed width, B & C
54 in.
Bed height, D
21 in.
Top of fender height,
Fender length, F
52 in.
NOTE: The trailer chassis ball be as shown on the drawings and the technical data estimated in this table I
is solely for quick reference and identification only.
TABLE II. Components of military design trailer chassis.
a. Intervehicular
Military types per drawings.
connections
Service on curbside.
Emer. on roadside.
Lines routed and protected to prevent damage
from dropping of military cargo truck tailgate.
b. Suspension
Trailing arm with quarter-elliptic leaf springs
per drawings.
Contractor's trailer model to include the dash
number of the standard various spring dash-l
when specified (see 6.2, T-2), optional springs
furnished as follows:
Dash - 1.
8700 lb. GVWR chassis, standard. l /
Dash - 2.
7700 lb. GVWR chassis, option.
Dash - 3.
6700 lb. GVWR chassis, option.
Dash - 4.
5700 lb. GVWR chassis, option.
Dash - 5.
4700 lb. GVWR chassis,option.
Dash - 6.
3700 lb. GVWR chassis,option.
