MIL-C-52437/3
TABLE I. Size 4 chassis. (Cont'd)
Running gear options
Option A:
No. of axles
1 ea.
- GAWR, ea. axle at hubs
Minimum
5000 lb.
- No. trailer tires
2 ea.
No. spare tires
1 ea.
Tire size
12-16.5
Load range
LR E (10 PR)
Tire inf. press
Maximum
35 psi
Option B:
No. of axles
2 ea.
- GAWR, ea. axle at hubs
Minimum
5000 lb.
- No. trailer tires
4 ea.
No. spare tires
1 ea.
Tire size
12-16.5
Load range
LR E (10 PR)
Tire inf. press.
Maximum
35 psi.
Bed length, A,
Minimum
120 in.
Bed width, B &.C
Minimum
48 in.
Bed height, D
Maximum
30 in.
Top of fender height, E
Maximum
50 in.
Fender length, F:
Single axle
Maximum
50 in.
Tandem axle
Maximum
108 in.
