MIL-C-52437/9
18 October 1983
MILITARY SPECIFICATION SHEET
CHASSIS, TRAILER, SIZE 32, CCE
This specification is approved for use by all Departments and Agencies of the Department of
Defense.
The complete requirements for acquiring the size 32 trailer chassis described herein shall consist of this
document and the latest issue of specification MIL-C-52437.
REQUIREMENTS:
1. The trailer chassis shall be intended for towing by heavy trucks and off-road equipment.
2. The trailer chassis and platform characteristics shall be in accordance with table I, table II,
and as shown in figure 1.
TABLE I. Size 32 Chassis with platform.
GVWR per DOT
Minimum
32,000 lb.
Payload capacity
Minimum
23,000 lb.
Trailer curb weight
Maximum
8,800 lb.
Tow eye weight
Range
5 to1 Percent
OAL
Maximum
330 in.
OAH
Minimum
Practical
OAW
Maximum
96 in.
Drawbar length
Minimum
72 in.
Suspension travel, mech. susp.
Minimum
6 in.
air ride
Minimum
8 in.
Running gear, standard
No. of axles
2 ea.
- GAWR, ea. axle at hubs
Minimum
19,000 lb.
- No. trailer tires
8 ea.
No. spare tires
1 ea.
Tire size
l0.00 15. TR
Load range
LR F (8 PR)
Tire inf. press.
Maximum
80 psi
Running gear options
Option A:
No. of axles
3 ea.
- GAWR, ea. axle at hubs
Minimum
17,000 lb.
FSC 2330
1 of 4
