MIL-C-52437/8
18 October 1983
MILITARY SPECIFICATION SHEET
CHASSIS, TRAILER, SIZE 14, CCE
This specification is approved for use by all Departments and Agencies of the Department of
Defense.
The complete requirements for acquiring the size 14 trailer chassis described herein shall consist of this
document and the latest issue of specification MIL-C-52437.
REQUIREMENTS:
1. The trailer chassis shall be intended for towing by heavy trucks and off-road equipment.
2. The trailer chassis characteristics shall be in accordance with table I and as shown in figure 1.
TABLE I. Size 14 Chassis.
GVWR per DOT
Minimum
14,000 lb.
Payload capacity
Minimum
11,000 lb.
Trailer curb weight
Maximum
4,200 lb.
Tow eye weight
Range
5 to 12 Percent
OAL
Maximum
330 in.
OAH
Minimum
Practical
OAW
Maximum
96 in.
Drawbar length
Minimum
72 in.
Suspension travel, single axle
Minimum
4 in.
Suspension travel, multi-axle
Minimum
8 in.
Running gear, standard
No. of axles
3 ea.
- GAWR, ea. axle at hubs
Minimum
6,000 lb.
- No. trailer tires
6 ea.
No. spare tires
1 ea.
Tire size
9.50 -16.5
Load range
LR D (8 PR)
Tire inf. press.
Maximum
35 psi
Running gear options
Option A:
No. of axles
2 ea.
- GAWR, ea. axle at hubs
Minimum
8,000 lb.
FSC 2330
1of 3
